Gross capacity | Approx.4.5CBF/128Ltrs |
Voltage | GEI-128C4 |
Power consumption | Approx.45w |
Temperature range | Ambient temperature to -18°C, adjustable via Ditigal display&control System |
Insulation | CFC-free polyurethane foam |
System | Fully hermetic compressor with integrated control electronics, low-voltage protection adjustable for consumer or starter battery by means of electronics, electronic fuse/automatic reverse pole protection, tuble on sheet evaporator ,and efficent finned tube condenser |
Material | Prepainted steel |
Colour | White Grey |
Weight | Approx.57 kg/62 kg |
Quality features | 1:Direct connect to DC12V or DC 24v. 2:Anti discharge protection for Battery. 3:Automatic turn off when voltage is low. 4:Extermely strong Lid,Hinge and safty Lock. 5:Celsius Scale/ Fahrenheit scale. 6:intelligent to operate – preset feature. 7:Self-Detecting 9 faults& alarms. 8:built-in fan forcing ventilation system. 9: Chest type or stand up – reversible. 10:110mm insulation wall ,CFC Free. 11:Easy operation Safety lock. 12:Cabinet lamp. 13:Ultra Energy Efficient , 420wh/24hrs at 32C under freeze mode. 14:Temperature record and alarm system, can be used a medial refrigerator. |
Accessory | AC/DC ADAPTOR |
Loading quantity | 112pcs/20GP 240PCS/40HQ |
MOQ | 2 PCS |
Carton dimension | 852*741*847 |
Product dimension | 804*726*810 |
Inner Cabinet | 600*450*550 (230) |
Warranty | One Year |
168-Litres
Gross capacity | Approx.6.0CBF/168Ltrs |
Voltage | GEI-168C4 |
Power consumption | Approx.45w |
Temperature range | Ambient temperature to -18°C, adjustable via Ditigal display&control System |
Insulation | CFC-free polyurethane foam |
System | Fully hermetic compressor with integrated control electronics, low-voltage protection adjustable for consumer or starter battery by means of electronics, electronic fuse/automatic reverse pole protection, tuble on sheet evaporator ,and efficent finned tube condenser |
Material | Prepainted steel |
Colour | White Grey |
Weight | Approx.63 kg/68 kg |
Quality features | 1:Direct connect to DC12V or DC 24v. 2:Anti discharge protection for Battery. 3:Automatic turn off when voltage is low. 4:Extermely strong Lid,Hinge and safty Lock. 5:Celsius Scale/ Fahrenheit scale. 6:intelligent to operate – preset feature. 7:Self-Detecting 9 faults& alarms. 8:built-in fan forcing ventilation system. 9: Chest type or stand up – reversible. 10:110mm insulation wall ,CFC Free. 11:Easy operation Safety lock. 12:Cabinet lamp. 13:Ultra Energy Efficient , 420wh/24hrs at 32C under freeze mode. 14:Temperature record and alarm system, can be used a medial refrigerator. |
Accessory | AC/DC ADAPTOR |
Loading quantity | 84pcs/20GP 240PCS/40HQ |
MOQ | 2 PCS |
Carton dimension | 852*741*997 |
Product dimension | 804*726*960 |
Inner Cabinet | 600*450*700 (230) |
Warranty | One Year |
How does the DC Powered Refrigerator / Freezer Work?
The solar panel converts sunlight into DC power or electricity to charge the battery. This electricity (charge) is controlled via a charge controller which ensures that battery is properly charged and not damaged. DC appliances can then be powered directly from the battery.
Multifunctional refrigerator/freezer
Option 1. Accessory: AC/DC adaptor.
The DC refrigerator/freezer can be powered by AC power (standard wall plug in a home or office). This allows the refrigerator to be powered using conventional wall outlets and the unit can work without solar panels, batteries or a charge controller. It is important to note that our units operate with as little as 60W.
Option 2. Accessory: solar panels, battery, charge controller.
The solar panel converts sunlight into DC power or electricity to charge the battery. This electricity(charge) is controlled via a charge controller which ensures that the battery is charged properly and not damaged. The solar refrigerator/freezer can then be powered directly from the battery.
Option 3. Accessory: charge controller,solar panel,battery, AC/DC auto transfer switch, AC/DC adaptor.
This option combines option 1 and 2. By adding a AC/DC auto transfer switch, the refrigerator can operate using AC power. This is useful when the battery is discharged due to multiple rainy or cloudy days. When the battery can’t provide needed electricity, the auto transfer switch can automatically switch to AC electricity (110v/220v). When the battery is recharged, the refrigerator will go back to DC solar power(12v/24v).
AC/DC automatic switch
The automatic switch allows for power priority. If plugged into the DC port, the battery has priority. The system will operate using DC (battery power) and will only switch to AC power if the battery is exhausted. If plugged into the AC port, the system will operate using AC power and will switch to DC power (battery) only in the case of a power outage. The DC port is preferred as this does not cost any money to operate.
